Linea-Q1/Q2 L Lente

/
The Karizma Luce Linea-Q1 /Q2 L Lente is a 48V Q-Line fixture of the Delizia Di Luce collection. Made from aluminium. Available luminaire flux: 2250 and 2400 lm. CCT: 3000K, 4000K. Beam angle: 15°, 30° and 45°. Luminaire available in black and white.
Aktiva filter: 6/6
Q652HB93015F0 3000 K Black 3000 K 930 (3000K / CRI90) 15 ° 2250 lm
Q652HB93030F0 3000 K Black 3000 K 930 (3000K / CRI90) 30 ° 2250 lm
Q652HB93045F0 3000 K Black 3000 K 930 (3000K / CRI90) 45 ° 2250 lm
Q652HB94015F0 4000 K Black 4000 K 940 (4000K / CRI90) 15 ° 2400 lm
Q652HB94030F0 4000 K Black 4000 K 940 (4000K / CRI90) 30 ° 2400 lm
Q652HB94045F0 4000 K Black 4000 K 940 (4000K / CRI90) 45 ° 2400 lm
Q652HW93015F0 3000 K White 3000 K 930 (3000K / CRI90) 15 ° 2250 lm
Q652HW93030F0 3000 K White 3000 K 930 (3000K / CRI90) 30 ° 2250 lm
Q652HW93045F0 3000 K White 3000 K 930 (3000K / CRI90) 45 ° 2250 lm
Q652HW94015F0 4000 K White 4000 K 940 (4000K / CRI90) 15 ° 2400 lm
Q652HW94030F0 4000 K White 4000 K 940 (4000K / CRI90) 30 ° 2400 lm
Q652HW94045F0 4000 K White 4000 K 940 (4000K / CRI90) 45 ° 2400 lm
    • Chromaticity tolerance 3 MacAdam
    • CRI 90
    • Housing material Aluminum Die Cast
    • Warranty 5Y
    • IP klass IP20
    • Drivdon Included ON/OFF
    • CCT 4000K, 3000K
    • Lumen 2250lm, 2400lm
    • System power 28W
    • Optic Reflector
    • Light source 930 (3000K / CRI90), 940 (4000K / CRI90)
    • Dimring DALI
    • Product tags 48V
    • Färg på armatur Black, White
    • Livslängd 50 000h
    • Light Color CCT 4000K, 3000K
    • Elclass Class III
    • Mains voltage 48V
    • System efficiency 70lm/W, 64lm/W
    • Mått 433x22x25mm
    • Ljusspridning 45°, 30°, 15°
