Delizia di Luce
Tesoro
The Tesoro is a track led spotlight, luxurious and extremely versatile. This small LED track spot is for use on a 3-phase rail. This makes the Karizma Luce Tesoro the luminaire of choice in a retail environment. Choose from several options in colour, controllability, CCT and beam angles. No wonder the elegant Tesoro is a favourite among lighting designers.
/
The Tesoro is a track led spotlight, luxurious and extremely versatile. This small LED track spot is for use on a 3-phase rail. This makes the Karizma Luce Tesoro the luminaire of choice in a retail environment. Choose from several options in colour, controllability, CCT and beam angles. No wonder the elegant Tesoro is a favourite among lighting designers.
| cct | 2700K3000K4000K |
| chromaticity tolerance | 3 MacAdam |
| cutout dimension | N/A |
| elclass | Class I |
| housingmaterial | Aluminum Die Cast |
| ip rating | IP20 |
| led power w | N/A |
| lifetime | 50000h |
| lightsource | 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90) |
| lightsource energyclass | E |
| lightsource identifier | BXRE-27G20FH-B-83BXRE-30G20FH-B-83BXRE-40G20FH-B-83L2C5-27901205F1300L2C5-30901205F1300L2C5-40901205F1300 |
| luminaire color | BlackWhite |
| luminaire dimension | Ø70x180mm |
| lightsource energy class | E |
| mains voltage | 220-240V / 50 -60Hz |
| netweight | 01.32 |
| nominal fa ma | N/A |
| nominal fv v | N/A |
| optic | Reflector |
| powersupply | Included ON/OFF |
| reflector color | Specular Aluminium |
| system efficiency | 100lm/W105lm/W110.5lm/W82lm/W87lm/W95lm/W |
| system power | 19W |
| warranty | 5Y |
Tesoro - Varianter
| Bild | SKU | CCT | Chromaticity tolerance | Cutout dimension | Elclass | Housingmaterial | IP rating | LED Power (W) | Lifetime | Lightsource | Lightsource energyclass | Lightsource identifier | Luminaire color | Luminaire dimension | Lightsource energy class | Mains voltage | Netweight | Nominal fA [mA] | Nominal fV [V] | Optic | Powersupply | Reflector color | System efficiency | System power | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
6032GB92745F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
6032GB93020F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
|
6032GB93030F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
|
6032GB93045F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
6032GW92720F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
6032GW92730F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
6032GW92745F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
6032GW93020F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
|
6032GW93030F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
|
6032GW93045F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | BXRE-30G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 105lm/W | 19W | 5Y | |
|
|
6032HB94020F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032HB94030F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032HB94045F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032HW94020F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032HW94030F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032HW94045F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | BXRE-40G20FH-B-83 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 110.5lm/W | 19W | 5Y | |
|
|
6032GB92720F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
6032GB92730F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | BXRE-27G20FH-B-83 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 100lm/W | 19W | 5Y | |
|
|
603HB94045F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y | |
|
|
603GW92720F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GW92730F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GW92745F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GB92720F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GB92730F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GB92745F0 | 2700K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 927 (2700K / CRI90) | E | L2C5-27901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 82lm/W | 19W | 5Y | |
|
|
603GW93020F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603GW93030F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603GW93045F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603GB93020F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603GB93030F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603GB93045F0 | 3000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 930 (3000K / CRI90) | E | L2C5-30901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 87lm/W | 19W | 5Y | |
|
|
603HW94020F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y | |
|
|
603HW94030F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y | |
|
|
603HW94045F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | White | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y | |
|
|
603HB94020F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y | |
|
|
603HB94030F0 | 4000K | 3 MacAdam | N/A | Class I | Aluminum Die Cast | IP20 | N/A | 50000h | 940 (4000K / CRI90) | E | L2C5-40901205F1300 | Black | Ø70x180mm | E | 220-240V / 50 -60Hz | 01.32 | N/A | N/A | Reflector | Included ON/OFF | Specular Aluminium | 95lm/W | 19W | 5Y |
