Delizia di Luce

Corsa Lente

The Corsa Lente is an adjustable led downlight with an optical lens. The clean design and its ability to rotate 350° makes it the perfect choice for office lighting, catering lighting and residential lighting. Simply highlight exactly the way you want it.

iconwarranty5-41.svg icondali-39.svg icondimtowarm-36.svg iconreplaceablecontrol-37.svg iconreplaceableled-37.svg iconphasecutdim-31.svg
/

The Corsa Lente is an adjustable led downlight with an optical lens. The clean design and its ability to rotate 350° makes it the perfect choice for office lighting, catering lighting and residential lighting. Simply highlight exactly the way you want it.

cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension Ø100mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP43/IP20
led power w 12.5W9W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier BXRE-27G0800-D-73BXRE-30G0800-D-73BXRE-40G0800-D-73CLU028-1204C4-403H5M3-F1
luminaire color BlackWhite
luminaire dimension Ø110x77mm
lightsource energy class EF
mains voltage N/A
netweight 00.42
nominal fa ma 350mA500mA
nominal fv v 18.4V33.8-35.9V
optic Lens
powersupply Separate Available
reflector color N/A
system efficiency 103lm/W61lm/W63lm/W74lm/W89lm/W91lm/W
system power 11.5W14W
product tags Phased out
warranty 5Y

Corsa Lente - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Product tags Warranty
116CW9272200 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CW9302200 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116CW9273600 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CW9303600 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116CW9276000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CW9306000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116CB9272200 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CB9302200 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116CB9273600 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CB9303600 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116CB9276000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 61lm/W 11.5W Phased out 5Y
116CB9306000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 63lm/W 11.5W Phased out 5Y
116EW9273000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FW9303000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116EW9274000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FW9304000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116EW9276000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FW9306000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116EB9273000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FB9303000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116EB9274000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FB9304000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116EB9276000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 14W Phased out 5Y
116FB9306000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black Ø110x77mm F N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 14W Phased out 5Y
116GB9403000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116DB9402200 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
116DB9403600 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
116DB9406000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
116DW9402200 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
116GB9404000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116GB9406000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116GW9403000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116GW9404000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116GW9406000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø110x77mm E N/A 00.42 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 14W Phased out 5Y
116DW9403600 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
116DW9406000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White Ø110x77mm F N/A 00.42 500mA 18.4V Lens Separate Available N/A 74lm/W 11.5W Phased out 5Y
