Delizia di Luce

Piazza

Categories: , ,

The Piazza is an adjustable led downlight. Besides his stylish square looks, also his versatility is striking. The Karizma Luce Piazza can be ordered with a 30°/45°/60° or 36°/45°/60° aluminium reflector and is 350° rotatable. This takes ambient lighting to another level.

iconwarranty5-50.svg icondali-49.svg icondimtowarm-43.svg iconreplaceablecontrol-49.svg iconreplaceableled-49.svg iconphasecutdim-44.svg
/

The Piazza is an adjustable led downlight. Besides his stylish square looks, also his versatility is striking. The Karizma Luce Piazza can be ordered with a 30°/45°/60° or 36°/45°/60° aluminium reflector and is 350° rotatable. This takes ambient lighting to another level.
cct 2700K3000K4000K
chromaticity tolerance 10 MacAdam11 MacAdam12 MacAdam13 MacAdam14 MacAdam15 MacAdam3 MacAdam4 MacAdam5 MacAdam6 MacAdam7 MacAdam8 MacAdam9 MacAdam
cutout dimension Ø100mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP43/IP20IP43/IP21IP43/IP22IP43/IP23IP43/IP24IP43/IP25IP43/IP26IP43/IP27IP43/IP28IP43/IP29IP43/IP30IP43/IP31IP43/IP32
led power w 12.5W9W
lifetime 50000h
lightsource 840 (4000K / CRI80)927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI80)940 (4000K / CRI90)
lightsource energyclass F
lightsource identifier BXRE-27G0800-D-73BXRE-30G0800-D-73BXRE-40G0800-D-73
luminaire color BlackWhite
luminaire dimension 110x110x77mm
lightsource energy class F
mains voltage N/A
netweight 00.44
nominal fa ma 350mA500mA
nominal fv v 18.4V33.8-35.9V
optic Reflector
powersupply Separate Available
reflector color Specular Aluminium
system efficiency 111lm/W61lm/W63lm/W79lm/W89lm/W91lm/W
system power 11.5W14W
warranty 5Y

Piazza - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
119EW9276000 2700K 5 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP22 12.5W 50000h 927 (2700K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119CB9276000 2700K 6 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP23 9W 50000h 927 (2700K / CRI90) Black 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119CW9276000 2700K 7 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP24 9W 50000h 927 (2700K / CRI90) White 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119FB9306000 3000K 8 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP25 12.5W 50000h 930 (3000K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119FW9306000 3000K 9 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP26 12.5W 50000h 930 (3000K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119CB9306000 3000K 10 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP27 9W 50000h 930 (3000K / CRI90) Black 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119CW9306000 3000K 11 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP28 9W 50000h 930 (3000K / CRI90) White 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119EB9276000 2700K 4 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP21 12.5W 50000h 927 (2700K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119GB9406000 4000K 12 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP29 12.5W 50000h 940 (4000K / CRI80) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
119GW9406000 4000K 13 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP30 12.5W 50000h 940 (4000K / CRI80) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
119DB9406000 4000K 14 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP31 9W 50000h 940 (4000K / CRI80) Black 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 111lm/W 11.5W 5Y
119DW9406000 4000K 15 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP32 9W 50000h 940 (4000K / CRI80) White 110x110x77mm N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 111lm/W 11.5W 5Y
119CW9304500 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119CB9273000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119CB9303000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119CB9274500 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119CB9304500 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119EW9273600 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119FW9303600 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119EW9274500 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119FW9304500 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119EB9273600 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119FB9303600 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119EB9274500 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 927 (2700K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 89lm/W 14W 5Y
119FB9304500 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 930 (3000K / CRI90) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 91lm/W 14W 5Y
119CW9273000 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119CW9303000 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 63lm/W 11.5W 5Y
119CW9274500 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 61lm/W 11.5W 5Y
119GW9404500 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 840 (4000K / CRI80) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
119DB9403000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 79lm/W 11.5W 5Y
119DB9404500 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 79lm/W 11.5W 5Y
119DW9403000 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 79lm/W 11.5W 5Y
119DW9404500 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 110x110x77mm F N/A 00.44 500mA 18.4V Reflector Separate Available Specular Aluminium 79lm/W 11.5W 5Y
119GB9403600 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 840 (4000K / CRI80) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
119GB9404500 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 840 (4000K / CRI80) Black 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
119GW9403600 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP43/IP20 12.5W 50000h 840 (4000K / CRI80) White 110x110x77mm N/A 00.44 350mA 33.8-35.9V Reflector Separate Available Specular Aluminium 111lm/W 14W 5Y
