Dea Della Luce

Dea Charon XS

Categories: , ,

The Dea Charon is named after the Roman goddess Charon, who protects and keeps healthy. It can play a vital role in your lighting plan. Available in black and white, and with numerous colour options for the reflector. Choose from various applications and extensive package of dimming options and bring any interior to a higher level.

iconwarranty5-64.svg icondali-64.svg icondimtowarm-56.svg iconreplaceablecontrol-61.svg iconreplaceableled-61.svg iconphasecutdim-58.svg
/

The Dea Charon is named after the Roman goddess Charon, who protects and keeps healthy. It can play a vital role in your lighting plan. Available in black and white, and with numerous colour options for the reflector. Choose from various applications and extensive package of dimming options and bring any interior to a higher level.
cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension Ø75mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP20
led power w 6.2W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
luminaire color BlackWhite
luminaire dimension Ø40mm
mains voltage N/A
netweight 0,4
nominal fa ma 200mA
nominal fv v 31V
optic Reflector
powersupply Separate Available
reflector color Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite
system efficiency 70lm/W73lm/W
system power 7W
warranty 5Y

Dea Charon XS - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Luminaire color Luminaire dimension Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
136CB92734SG00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 70lm/W 7W 5Y
136CB93034SG00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 7W 5Y
136CB94034SG00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 73lm/W 7W 5Y
136CB92734BG00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 70lm/W 7W 5Y
136CB93034BG00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 7W 5Y
136CB94034BG00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 73lm/W 7W 5Y
136CB92734WH00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 70lm/W 7W 5Y
136CB93034WH00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 7W 5Y
136CB94034WH00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 73lm/W 7W 5Y
136CW92734SG00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 70lm/W 7W 5Y
136CW93034SG00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 7W 5Y
136CW94034SG00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Silver High Gloss 73lm/W 7W 5Y
136CW92734BG00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 70lm/W 7W 5Y
136CW93034BG00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 7W 5Y
136CB92734CH00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 70lm/W 7W 5Y
136CB93034CH00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 7W 5Y
136CB94034CH00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 73lm/W 7W 5Y
136CB92734GO00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 70lm/W 7W 5Y
136CB93034GO00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 7W 5Y
136CB94034GO00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 73lm/W 7W 5Y
136CW94034BG00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black High Gloss 73lm/W 7W 5Y
136CW92734WH00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 70lm/W 7W 5Y
136CW93034WH00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 7W 5Y
136CW94034WH00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available White 73lm/W 7W 5Y
136CW92734CH00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 70lm/W 7W 5Y
136CB92734BM00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 70lm/W 7W 5Y
136CB93034BM00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 7W 5Y
136CB94034BM00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 73lm/W 7W 5Y
136CW93034CH00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 7W 5Y
136CW94034CH00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Chrome 73lm/W 7W 5Y
136CW92734GO00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 70lm/W 7W 5Y
136CW93034GO00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 7W 5Y
136CW94034GO00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Gold 73lm/W 7W 5Y
136CW92734BM00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 70lm/W 7W 5Y
136CW93034BM00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 7W 5Y
136CW94034BM00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Black Matt 73lm/W 7W 5Y
136CW92734CO00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 70lm/W 7W 5Y
136CW93034CO00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 7W 5Y
136CW94034CO00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) White Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 73lm/W 7W 5Y
136CB92734CO00 2700K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 927 (2700K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 70lm/W 7W 5Y
136CB93034CO00 3000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 930 (3000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 7W 5Y
136CB94034CO00 4000K 3 MacAdam Ø75mm Class II Aluminum Die Cast IP20 6.2W 50000h 940 (4000K / CRI90) Black Ø40mm N/A 0,4 200mA 31V Reflector Separate Available Copper 73lm/W 7W 5Y
