Dea Della Luce

Dea Ceres S duo

Let’s double up! The same charming looks and double the possibilities. Just adjust your beam angle and flux according to your required illumination. Create exactly your atmosphere of choice thanks to the various colours and dim to warm option. The high CRI and 4000K possibilities enable the Dea Concordia to freshen up any office. Available in small and medium size. On request available in 24°

iconwarranty5-103.svg icondali-98.svg icondimtowarm-88.svg iconreplaceablecontrol-94.svg iconreplaceableled-94.svg iconphasecutdim-83.svg
/

Let’s double up! The same charming looks and double the possibilities. Just adjust your beam angle and flux according to your required illumination. Create exactly your atmosphere of choice thanks to the various colours and dim to warm option. The high CRI and 4000K possibilities enable the Dea Concordia to freshen up any office. Available in small and medium size. On request available in 24°

cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension 165x80mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP20
led power w 2x8.5W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier CLU028-1204C4-273H5M3-F1CLU028-1204C4-303H5M3-F1CLU028-1204C4-403H5M3-F1
luminaire color BlackWhite
luminaire dimension 170x86x63mm
lightsource energy class EF
mains voltage N/A
nominal fa ma 250mA
nominal fv v 33.2V
optic Reflector
powersupply Separate Available
reflector color Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite
system efficiency 72lm/W76lm/W77lm/W79lm/W80lm/W82lm/W83lm/W84lm/W85lm/W86lm/W89lm/W90lm/W91lm/W
system power 2x10.5W
warranty 5Y

Dea Ceres S duo - Varianter

SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
132DW92740SG00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 2x10.5W 5Y
132DB93040SG00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 2x10.5W 5Y
132DB94040SG00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 2x10.5W 5Y
132DB92740BG00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 2x10.5W 5Y
132DB93040BG00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 2x10.5W 5Y
132DB94040BG00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 2x10.5W 5Y
132DB92740WH00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available White 80lm/W 2x10.5W 5Y
132DW92740BG00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 2x10.5W 5Y
132DW92740WH00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available White 80lm/W 2x10.5W 5Y
132DB93040WH00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available White 84lm/W 2x10.5W 5Y
132DB94040WH00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available White 85lm/W 2x10.5W 5Y
132DB92740CH00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Chrome 85lm/W 2x10.5W 5Y
132DB93040CH00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Chrome 89lm/W 2x10.5W 5Y
132DB94040CH00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Chrome 90lm/W 2x10.5W 5Y
132DB92740GO00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Gold 80lm/W 2x10.5W 5Y
132DB93040GO00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Gold 84lm/W 2x10.5W 5Y
132DB94040GO00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Gold 85lm/W 2x10.5W 5Y
132DB92740CO00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Copper 80lm/W 2x10.5W 5Y
132DW92740CH00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Chrome 85lm/W 2x10.5W 5Y
132DW92740GO00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Gold 80lm/W 2x10.5W 5Y
132DB93040CO00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Copper 84lm/W 2x10.5W 5Y
132DB94040CO00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Copper 85lm/W 2x10.5W 5Y
132DB92740BM00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 2x10.5W 5Y
132DB93040BM00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 2x10.5W 5Y
132DB94040BM00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 2x10.5W 5Y
132DW92740CO00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Copper 80lm/W 2x10.5W 5Y
132DW92740BM00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 2x10.5W 5Y
132DB92740SG00 2700K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 170x86x63mm F N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 2x10.5W 5Y
132DW93040SG00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 2x10.5W 5Y
132DW94040SG00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 2x10.5W 5Y
132DW93040BG00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 2x10.5W 5Y
132DW94040BG00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 2x10.5W 5Y
132DW93040WH00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available White 84lm/W 2x10.5W 5Y
132DW94040WH00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available White 85lm/W 2x10.5W 5Y
132DW93040CH00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Chrome 89lm/W 2x10.5W 5Y
132DW94040CH00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Chrome 90lm/W 2x10.5W 5Y
132DW93040GO00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Gold 84lm/W 2x10.5W 5Y
132DW94040GO00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Gold 85lm/W 2x10.5W 5Y
132DW93040CO00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Copper 84lm/W 2x10.5W 5Y
132DW94040CO00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Copper 85lm/W 2x10.5W 5Y
132DW93040BM00 3000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 2x10.5W 5Y
132DW94040BM00 4000K 3 MacAdam 165x80mm Class II Aluminum Die Cast IP20 2x8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White 170x86x63mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 2x10.5W 5Y
