Dea Della Luce

Dea Carmenta M

Categories: , ,

A true piece of art, just by the design itself. This beautiful adjustable luminaire offers a wide selection of different colours in reflectors. Thanks to its low glare, the Dea Carmenta gracefully enriches workspaces and offices, especially when you choose the White or Silver reflector. Go Black or Gold if you want to put an extra dimension to hotel or restaurant atmospheres. On request available in 24°.

iconwarranty5-5.svg icondali-5.svg icondimtowarm-5.svg iconreplaceablecontrol-5.svg iconreplaceableled-5.svg iconphasecutdim-5.svg icontunablewhite-1.svg
/

A true piece of art, just by the design itself. This beautiful adjustable luminaire offers a wide selection of different colours in reflectors. Thanks to its low glare, the Dea Carmenta gracefully enriches workspaces and offices, especially when you choose the White or Silver reflector. Go Black or Gold if you want to put an extra dimension to hotel or restaurant atmospheres. On request available in 24°.
cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension Ø100mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP20
led power w 12.5W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier CLU028-1204C4-273H5M3-F1CLU028-1204C4-303H5M3-F1CLU028-1204C4-403H5M3-F1
luminaire color BlackWhite
luminaire dimension Ø105x80mm
lightsource energy class EF
mains voltage N/A
netweight 00.34
nominal fa ma 350mA
nominal fv v 34.1V
optic Reflector
powersupply Separate Available
reflector color Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite
system efficiency 76lm/W80lm/W81lm/W83lm/W84lm/W86lm/W87lm/W89lm/W90lm/W91lm/W92lm/W93lm/W
system power 14W
warranty 5Y

Dea Carmenta M - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
130EB92740BG00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 81lm/W 14W 5Y
130EB93040BG00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 84lm/W 14W 5Y
130EB92740WH00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available White 83lm/W 14W 5Y
130EB93040WH00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available White 86lm/W 14W 5Y
130EB92740CH00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 86lm/W 14W 5Y
130EB92740GO00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Gold 83lm/W 14W 5Y
130EB93040GO00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Gold 86lm/W 14W 5Y
130EB92740CO00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Copper 83lm/W 14W 5Y
130EB93040CO00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Copper 86lm/W 14W 5Y
130EB92740SG00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 89lm/W 14W 5Y
130EB92740BM00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 76lm/W 14W 5Y
130EB93040BM00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 80lm/W 14W 5Y
130FB93040SG00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 92lm/W 14W 5Y
130FB94040SG00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 93lm/W 14W 5Y
130EW92740SG00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 89lm/W 14W 5Y
130FW93040SG00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 92lm/W 14W 5Y
130FW94040SG00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Silver High Gloss 93lm/W 14W 5Y
130EW92740BG00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 81lm/W 14W 5Y
130EB94040BG00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 86lm/W 14W 5Y
130EW93040BG00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 84lm/W 14W 5Y
130EW94040BG00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black High Gloss 86lm/W 14W 5Y
130EW92740WH00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available White 83lm/W 14W 5Y
130EW93040WH00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available White 86lm/W 14W 5Y
130EW94040WH00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available White 87lm/W 14W 5Y
130EW92740CH00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 86lm/W 14W 5Y
130FW93040CH00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 90lm/W 14W 5Y
130FW94040CH00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 91lm/W 14W 5Y
130EW92740GO00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Gold 83lm/W 14W 5Y
130EB94040WH00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available White 87lm/W 14W 5Y
130FB93040CH00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 90lm/W 14W 5Y
130FB94040CH00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Chrome 91lm/W 14W 5Y
130EW93040GO00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Gold 86lm/W 14W 5Y
130EW94040GO00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Gold 87lm/W 14W 5Y
130EW92740CO00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Copper 83lm/W 14W 5Y
130EW93040CO00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Copper 86lm/W 14W 5Y
130EW94040CO00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Copper 87lm/W 14W 5Y
130EW92740BM00 2700K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø105x80mm F N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 76lm/W 14W 5Y
130EW93040BM00 3000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 80lm/W 14W 5Y
130EW94040BM00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 81lm/W 14W 5Y
130EB94040GO00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Gold 87lm/W 14W 5Y
130EB94040CO00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Copper 87lm/W 14W 5Y
130EB94040BM00 4000K 3 MacAdam Ø100mm Class II Aluminum Die Cast IP20 12.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø105x80mm E N/A 00.34 350mA 34.1V Reflector Separate Available Black Matt 81lm/W 14W 5Y
