Emozione

The Emozione is a fixed led downlight. The recessed lamp position and square look make a gentle but powerful addition to your lighting plan. The Karizma Luce Emozione suits perfectly in hotels, restaurants, lobbies and hallways. Basically, every space which can use a touch of emotion.

Generera PDF Produktblad (PDF)
/
CRI
90
CCT
2700K, 2700K|3000K|4000K, 3000K, 4000K
Chromaticity tolerance
3 MacAdam, 3 MacAdam|4 MacAdam|5 MacAdam|6 MacAdam|7 MacAdam|8 MacAdam|9 MacAdam, 4 MacAdam, 5 MacAdam, 6 MacAdam, 7 MacAdam, 8 MacAdam, 9 MacAdam
Elclass
Class II
Housing material
Aluminum Die Cast
IP rating
IP43/IP20, IP43/IP20|IP43/IP21|IP43/IP22|IP43/IP23|IP43/IP24|IP43/IP25|IP43/IP26, IP43/IP21, IP43/IP22, IP43/IP23, IP43/IP24, IP43/IP25, IP43/IP26
Lifetime
50000h
Light source
927 (2700K / CRI90), 927 (2700K / CRI90)|930 (3000K / CRI90)|940 (4000K / CRI90)|Dim to Warm (1800K - 3000K / CRI90), 930 (3000K / CRI90), 940 (4000K / CRI90)
Light source energy class
F
Light source identifier
BXRE-27G0800-D-73, BXRE-27G0800-D-73|BXRE-30G0800-D-73|BXRE-40G0800-D-73, BXRE-30G0800-D-73, BXRE-40G0800-D-73
Luminaire color
Black, Black|White, White
Luminaire dimension
105x105x99mm
Mains voltage
N/A
Net weight (kg)
0.3
Nominal fV (V)
18.4V, 500mA
Nominal fA (mA)
500mA
Optic
Reflector
Power supply
Separate Available
Reflector color
Specular Aluminium
System efficiency
64lm/W, 64lm/W | 65lm/W | 74lm/W, 65lm/W, 74lm/W
System power
11.5W, 11.5W|11W, 11W
Warranty
5Y
Light Color CCT
2700, 2700|3000|4000, 3000, 4000
Power (W)
9W
Lumen
705 lm, 705 lm|705lm|720 lm|720lm|850 lm|850lm, 705lm, 720 lm, 720lm, 850 lm, 850lm
Beam angle
30°, 45°, 60°
Voltage (V)
18.4V
