Delizia di Luce

Emozione

Categories: , ,

The Emozione is a fixed led downlight. The recessed lamp position and square look make a gentle but powerful addition to your lighting plan. The Karizma Luce Emozione suits perfectly in hotels, restaurants, lobbies and hallways. Basically, every space which can use a touch of emotion.

iconwarranty5-31.svg icondali-31.svg icondimtowarm-29.svg iconreplaceablecontrol-30.svg iconreplaceableled-30.svg iconphasecutdim-29.svg
/

The Emozione is a fixed led downlight. The recessed lamp position and square look make a gentle but powerful addition to your lighting plan. The Karizma Luce Emozione suits perfectly in hotels, restaurants, lobbies and hallways. Basically, every space which can use a touch of emotion.
cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam4 MacAdam5 MacAdam6 MacAdam7 MacAdam8 MacAdam9 MacAdam
cutout dimension 97x97mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP43/IP20IP43/IP21IP43/IP22IP43/IP23IP43/IP24IP43/IP25IP43/IP26
led power w 9W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass F
lightsource identifier BXRE-27G0800-D-73BXRE-30G0800-D-73BXRE-40G0800-D-73
luminaire color BlackWhite
luminaire dimension 105x105x99mm
lightsource energy class F
mains voltage N/A
netweight 0.3
nominal fa ma 500mA
nominal fv v 18.4V
optic Reflector
powersupply Separate Available
reflector color Specular Aluminium
system efficiency 64lm/W65lm/W74lm/W
system power 11.5W11W
warranty 5Y

Emozione - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
206CB9276000 2700K 4 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP21 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11.5W 5Y
206CW9276000 2700K 5 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP22 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11.5W 5Y
206CB9306000 3000K 6 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP23 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11.5W 5Y
206CW9306000 3000K 7 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP24 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11.5W 5Y
206DB9406000 4000K 8 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP25 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
206DW9406000 4000K 9 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP26 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
206CW9273000 2700K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11W 5Y
206CW9303000 3000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11W 5Y
206CW9274500 2700K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11W 5Y
206CW9304500 3000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11W 5Y
206CB9273000 2700K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11W 5Y
206CB9303000 3000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11W 5Y
206CB9274500 2700K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 64lm/W 11W 5Y
206CB9304500 3000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 65lm/W 11W 5Y
206DB9403000 4000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
206DB9404500 4000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
206DW9403000 4000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
206DW9404500 4000K 3 MacAdam 97x97mm Class II Aluminum Die Cast IP43/IP20 9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 105x105x99mm F N/A 0.3 500mA 18.4V Reflector Separate Available Specular Aluminium 74lm/W 11.5W 5Y
