Delizia di Luce
Dimora
The Dimora is an adjustable led downlight. Choose a 24°, 36° or 44° aluminium reflector and create a lighting experience that enchants visitors over and over again. The Karizma Luce Dimora fits perfectly in any residential lighting project: in the kitchen, living, bedroom or entrance.
/
The Dimora is an adjustable led downlight. Choose a 24°, 36° or 44° aluminium reflector and create a lighting experience that enchants visitors over and over again. The Karizma Luce Dimora fits perfectly in any residential lighting project: in the kitchen, living, bedroom or entrance.
| cct | 2700K3000K4000K |
| chromaticity tolerance | 3 MacAdam |
| cutout dimension | Ø68mm |
| elclass | Class II |
| housingmaterial | Aluminum Die Cast |
| ip rating | IP44/IP20 |
| led power w | 9W |
| lifetime | 50000h |
| lightsource | 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90) |
| lightsource energyclass | F |
| lightsource identifier | BXRE-27G0800-D-73BXRE-30G0800-D-73BXRE-40G0800-D-73 |
| luminaire color | BlackWhite |
| luminaire dimension | Ø80x59mm |
| lightsource energy class | F |
| mains voltage | N/A |
| netweight | 00.16 |
| nominal fa ma | 500mA |
| nominal fv v | 18.4V |
| optic | Reflector |
| powersupply | Separate Available |
| reflector color | Specular Aluminium |
| system efficiency | 61lm/W63lm/W79lm/W |
| system power | 11.5W |
| warranty | 5Y |
Dimora - Varianter
| Bild | SKU | CCT | Chromaticity tolerance | Cutout dimension | Elclass | Housingmaterial | IP rating | LED Power (W) | Lifetime | Lightsource | Lightsource energyclass | Lightsource identifier | Luminaire color | Luminaire dimension | Lightsource energy class | Mains voltage | Netweight | Nominal fA [mA] | Nominal fV [V] | Optic | Powersupply | Reflector color | System efficiency | System power | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
112CW9272400 | 2700K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 927 (2700K / CRI90) | F | BXRE-27G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 61lm/W | 11.5W | 5Y | |
|
|
112CW9302400 | 3000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 930 (3000K / CRI90) | F | BXRE-30G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 63lm/W | 11.5W | 5Y | |
|
|
112CW9274000 | 2700K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 927 (2700K / CRI90) | F | BXRE-27G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 61lm/W | 11.5W | 5Y | |
|
|
112CW9304000 | 3000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 930 (3000K / CRI90) | F | BXRE-30G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 63lm/W | 11.5W | 5Y | |
|
112CB9272400 | 2700K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 927 (2700K / CRI90) | F | BXRE-27G0800-D-73 | Black | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 61lm/W | 11.5W | 5Y | |
|
|
112CB9302400 | 3000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 930 (3000K / CRI90) | F | BXRE-30G0800-D-73 | Black | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 63lm/W | 11.5W | 5Y | |
|
|
112CB9274000 | 2700K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 927 (2700K / CRI90) | F | BXRE-27G0800-D-73 | Black | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 61lm/W | 11.5W | 5Y | |
|
|
112DB9402400 | 4000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 940 (4000K / CRI90) | F | BXRE-40G0800-D-73 | Black | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 79lm/W | 11.5W | 5Y | |
|
|
112DB9404000 | 4000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 940 (4000K / CRI90) | F | BXRE-40G0800-D-73 | Black | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 79lm/W | 11.5W | 5Y | |
|
|
112DW9402400 | 4000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 940 (4000K / CRI90) | F | BXRE-40G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 79lm/W | 11.5W | 5Y | |
|
|
112DW9404000 | 4000K | 3 MacAdam | Ø68mm | Class II | Aluminum Die Cast | IP44/IP20 | 9W | 50000h | 940 (4000K / CRI90) | F | BXRE-40G0800-D-73 | White | Ø80x59mm | F | N/A | 00.16 | 500mA | 18.4V | Reflector | Separate Available | Specular Aluminium | 79lm/W | 11.5W | 5Y |
