Dea Della Luce
Dea Diana XS
When you want to go subtle, you have to go trimless. The Dea Diana offers a whole new lighting experience. The deep module, elegant looks and endless range of applications guarantee a refined look. Choose for a black or white housing and simply add a reflector in the colour of your choice. The standard installation frame is single, but you can choose also for a duo, triple, quadruple or square application. On request available in 24°.
/
When you want to go subtle, you have to go trimless. The Dea Diana offers a whole new lighting experience. The deep module, elegant looks and endless range of applications guarantee a refined look. Choose for a black or white housing and simply add a reflector in the colour of your choice. The standard installation frame is single, but you can choose also for a duo, triple, quadruple or square application. On request available in 24°.
| cct | 2700K3000K4000K |
| chromaticity tolerance | 3 MacAdam |
| cutout dimension | Ø82mm |
| elclass | Class II |
| housingmaterial | Aluminum Die Cast |
| ip rating | IP20 |
| led power w | 6.2W |
| lifetime | 50000h |
| lightsource | 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90) |
| lightsource energyclass | F |
| lightsource identifier | CLU701-1002C4-273H5K2CLU701-1002C4-303H5K2CLU701-1002C4-403H5K2 |
| luminaire color | BlackWhite |
| luminaire dimension | 105mmx89mm105mmx91,50mm |
| lightsource energy class | F |
| mains voltage | N/A |
| netweight | 0,3 |
| nominal fa ma | 200mA |
| nominal fv v | 31V |
| optic | Reflector |
| powersupply | Separate Available |
| reflector color | Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite |
| system power | 7W |
| product tags | Trimless |
| warranty | 5Y |
Dea Diana XS - Varianter
| Bild | SKU | CCT | Chromaticity tolerance | Cutout dimension | Elclass | Housingmaterial | IP rating | LED Power (W) | Lifetime | Lightsource | Lightsource energyclass | Lightsource identifier | Luminaire color | Luminaire dimension | Lightsource energy class | Mains voltage | Netweight | Nominal fA [mA] | Nominal fV [V] | Optic | Powersupply | Reflector color | System power | Product tags | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
224BW93034CO00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
|
224BW94034CO00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
224BW92734BM00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y | |
|
224BW92734SG00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx91,50mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
|
224BW93034BM00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y | |
|
|
224BW94034BM00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y | |
|
224BB92734SG00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
|
224BB93034SG00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
|
224BB94034SG00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
|
224BW93034SG00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx91,50mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
|
224BW94034SG00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx91,50mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Silver High Gloss | 7W | Trimless | 5Y | |
|
224BW92734BG00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
|
224BW93034BG00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
|
224BW94034BG00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
224BW92734WH00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
|
224BW93034WH00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
|
224BW94034WH00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
224BW92734CH00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
224BB92734BG00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
|
224BB93034BG00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
|
224BB94034BG00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black High Gloss | 7W | Trimless | 5Y | |
|
224BB92734WH00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
|
224BB93034WH00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
|
224BW93034CH00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
|
224BW94034CH00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
224BW92734GO00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
|
224BW93034GO00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
|
224BW94034GO00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
|
224BW92734CO00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | White | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
|
224BB94034WH00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | White | 7W | Trimless | 5Y | |
|
224BB92734CH00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
|
224BB93034CH00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
|
224BB94034CH00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Chrome | 7W | Trimless | 5Y | |
|
224BB92734GO00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
|
224BB93034GO00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
|
224BB94034GO00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Gold | 7W | Trimless | 5Y | |
|
224BB92734CO00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
|
224BB93034CO00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
|
224BB94034CO00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Copper | 7W | Trimless | 5Y | |
|
224BB92734BM00 | 2700K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 927 (2700K / CRI90) | F | CLU701-1002C4-273H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y | |
|
|
224BB93034BM00 | 3000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 930 (3000K / CRI90) | F | CLU701-1002C4-303H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y | |
|
|
224BB94034BM00 | 4000K | 3 MacAdam | Ø82mm | Class II | Aluminum Die Cast | IP20 | 6.2W | 50000h | 940 (4000K / CRI90) | F | CLU701-1002C4-403H5K2 | Black | 105mmx89mm | F | N/A | 0,3 | 200mA | 31V | Reflector | Separate Available | Black Matt | 7W | Trimless | 5Y |
