Dea Della Luce

Dea Diana S

Categories: , ,

When you want to go subtle, you have to go trimless. The Dea Diana, named after the moon goddess, offers a whole new lighting experience. The deep module, elegant looks and endless range of applications guarantee a refined look. Choose for a black or white housing and simply add a reflector in the colour of your choice. The standard installation frame is single, but you can choose also for a duo, triple, quadruple or quadruple square application. On request available in 24°.

iconwarranty5-42.svg icondali-42.svg icondimtowarm-38.svg iconreplaceablecontrol-41.svg iconreplaceableled-41.svg iconphasecutdim-38.svg icontrimless-1.svg
/

When you want to go subtle, you have to go trimless. The Dea Diana, named after the moon goddess, offers a whole new lighting experience. The deep module, elegant looks and endless range of applications guarantee a refined look. Choose for a black or white housing and simply add a reflector in the colour of your choice. The standard installation frame is single, but you can choose also for a duo, triple, quadruple or quadruple square application. On request available in 24°.
cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension Ø105mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP20
led power w 8.5W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier CLU028-1204C4-273H5M3-F1CLU028-1204C4-303H5M3-F1CLU028-1204C4-403H5M3-F1
luminaire color BlackWhite
luminaire dimension Ø130x74mm
lightsource energy class EF
mains voltage N/A
nominal fa ma 250mA
nominal fv v 33.2V
optic Reflector
powersupply Separate Available
reflector color Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite
system efficiency 72lm/W76lm/W77lm/W79lm/W80lm/W82lm/W83lm/W84lm/W85lm/W86lm/W89lm/W90lm/W91lm/W
system power 10.5W
product tags Trimless
warranty 5Y

Dea Diana S - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Product tags Warranty
220DB92740CH00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Chrome 85lm/W 10.5W Trimless 5Y
220DB92740BM00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 10.5W Trimless 5Y
220DB92740BG00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 10.5W Trimless 5Y
220DW92740SG00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 10.5W Trimless 5Y
220DW93040SG00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 10.5W Trimless 5Y
220DB93040WH00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available White 84lm/W 10.5W Trimless 5Y
220DB94040WH00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available White 85lm/W 10.5W Trimless 5Y
220DB93040CH00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Chrome 89lm/W 10.5W Trimless 5Y
220DB94040CH00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Chrome 90lm/W 10.5W Trimless 5Y
220DB92740GO00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Gold 80lm/W 10.5W Trimless 5Y
220DW94040SG00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 10.5W Trimless 5Y
220DW92740BG00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 10.5W Trimless 5Y
220DW93040BG00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 10.5W Trimless 5Y
220DW94040BG00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 10.5W Trimless 5Y
220DB93040GO00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Gold 84lm/W 10.5W Trimless 5Y
220DB94040GO00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Gold 85lm/W 10.5W Trimless 5Y
220DB92740CO00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Copper 80lm/W 10.5W Trimless 5Y
220DB93040CO00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Copper 84lm/W 10.5W Trimless 5Y
220DB94040CO00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Copper 85lm/W 10.5W Trimless 5Y
220DB93040BM00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 10.5W Trimless 5Y
220DB94040BM00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 10.5W Trimless 5Y
220DW92740WH00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available White 80lm/W 10.5W Trimless 5Y
220DW93040WH00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available White 84lm/W 10.5W Trimless 5Y
220DW94040WH00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available White 85lm/W 10.5W Trimless 5Y
220DW92740CH00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Chrome 85lm/W 10.5W Trimless 5Y
220DW93040CH00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Chrome 89lm/W 10.5W Trimless 5Y
220DW94040CH00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Chrome 90lm/W 10.5W Trimless 5Y
220DW92740GO00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Gold 80lm/W 10.5W Trimless 5Y
220DW93040GO00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Gold 84lm/W 10.5W Trimless 5Y
220DW94040GO00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Gold 85lm/W 10.5W Trimless 5Y
220DW92740CO00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Copper 80lm/W 10.5W Trimless 5Y
220DW93040CO00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Copper 84lm/W 10.5W Trimless 5Y
220DW94040CO00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Copper 85lm/W 10.5W Trimless 5Y
220DW92740BM00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 10.5W Trimless 5Y
220DW93040BM00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 10.5W Trimless 5Y
220DW94040BM00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 10.5W Trimless 5Y
220DB92740SG00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 10.5W Trimless 5Y
220DB93040SG00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 10.5W Trimless 5Y
220DB94040SG00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 10.5W Trimless 5Y
220DB93040BG00 3000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 10.5W Trimless 5Y
220DB94040BG00 4000K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø130x74mm E N/A 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 10.5W Trimless 5Y
220DB92740WH00 2700K 3 MacAdam Ø105mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø130x74mm F N/A 250mA 33.2V Reflector Separate Available White 80lm/W 10.5W Trimless 5Y
