Dea Della Luce

Dea Carmenta S

Categories: , ,

A true piece of art, just by the design itself. This beautiful adjustable luminaire offers a wide selection of different colours in reflectors. Thanks to its low glare, the Dea Carmenta gracefully enriches workspaces and offices, especially when you choose the White or Silver reflector. Go Black or Gold if you want to put an extra dimension to hotel or restaurant atmospheres. On request available in 24°.

iconwarranty5-26.svg icondali-25.svg icondimtowarm-25.svg iconreplaceablecontrol-26.svg iconreplaceableled-26.svg iconphasecutdim-25.svg
/

A true piece of art, just by the design itself. This beautiful adjustable luminaire offers a wide selection of different colours in reflectors. Thanks to its low glare, the Dea Carmenta gracefully enriches workspaces and offices, especially when you choose the White or Silver reflector. Go Black or Gold if you want to put an extra dimension to hotel or restaurant atmospheres. On request available in 24°.
cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension Ø80mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP20
led power w 8.5W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier CLU028-1204C4-273H5M3-F1CLU028-1204C4-303H5M3-F1CLU028-1204C4-403H5M3-F1
luminaire color BlackWhite
luminaire dimension Ø86x64mm
lightsource energy class EF
mains voltage N/A
netweight 00.24
nominal fa ma 250mA
nominal fv v 33.2V
optic Reflector
powersupply Separate Available
reflector color Black High GlossBlack MattChromeCopperGoldSilver High GlossWhite
system efficiency 72lm/W76lm/W77lm/W79lm/W80lm/W82lm/W83lm/W84lm/W85lm/W86lm/W89lm/W90lm/W91lm/W
system power 10.5W
warranty 5Y

Dea Carmenta S - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Warranty
128DW93040CH00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 89lm/W 10.5W 5Y
128DW94040CH00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 90lm/W 10.5W 5Y
128DW92740GO00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Gold 80lm/W 10.5W 5Y
128DW93040GO00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Gold 84lm/W 10.5W 5Y
128DW94040GO00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Gold 85lm/W 10.5W 5Y
128DW92740CO00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Copper 80lm/W 10.5W 5Y
128DW93040CO00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Copper 84lm/W 10.5W 5Y
128DW94040CO00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Copper 85lm/W 10.5W 5Y
128DW92740BM00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 10.5W 5Y
128DW93040BM00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 10.5W 5Y
128DW94040BM00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 10.5W 5Y
128DB92740SG00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 10.5W 5Y
128DB93040SG00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 10.5W 5Y
128DB93040BM00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 76lm/W 10.5W 5Y
128DB94040BM00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 77lm/W 10.5W 5Y
128DB94040SG00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 10.5W 5Y
128DB92740BG00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 10.5W 5Y
128DB93040BG00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 10.5W 5Y
128DB94040BG00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 10.5W 5Y
128DB92740WH00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available White 80lm/W 10.5W 5Y
128DB93040WH00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available White 84lm/W 10.5W 5Y
128DB94040WH00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available White 85lm/W 10.5W 5Y
128DB92740CH00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 85lm/W 10.5W 5Y
128DB93040CH00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 89lm/W 10.5W 5Y
128DB94040CH00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 90lm/W 10.5W 5Y
128DB92740GO00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Gold 80lm/W 10.5W 5Y
128DB93040GO00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Gold 84lm/W 10.5W 5Y
128DB94040GO00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Gold 85lm/W 10.5W 5Y
128DB92740CO00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Copper 80lm/W 10.5W 5Y
128DB93040CO00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Copper 84lm/W 10.5W 5Y
128DB94040CO00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 Black Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Copper 85lm/W 10.5W 5Y
128DB92740BM00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Black Matt 72lm/W 10.5W 5Y
128DW92740SG00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 86lm/W 10.5W 5Y
128DW93040SG00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 90lm/W 10.5W 5Y
128DW94040SG00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Silver High Gloss 91lm/W 10.5W 5Y
128DW92740BG00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 79lm/W 10.5W 5Y
128DW93040BG00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 82lm/W 10.5W 5Y
128DW94040BG00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available Black High Gloss 83lm/W 10.5W 5Y
128DW92740WH00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available White 80lm/W 10.5W 5Y
128DW93040WH00 3000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available White 84lm/W 10.5W 5Y
128DW94040WH00 4000K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 940 (4000K / CRI90) E CLU028-1204C4-403H5M3-F1 White Ø86x64mm E N/A 00.24 250mA 33.2V Reflector Separate Available White 85lm/W 10.5W 5Y
128DW92740CH00 2700K 3 MacAdam Ø80mm Class II Aluminum Die Cast IP20 8.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White Ø86x64mm F N/A 00.24 250mA 33.2V Reflector Separate Available Chrome 85lm/W 10.5W 5Y
