Dea Carmenta M
A true piece of art, just by the design itself. This beautiful adjustable luminaire offers a wide selection of different colours in reflectors. Thanks to its low glare, the Dea Carmenta gracefully enriches workspaces and offices, especially when you choose the White or Silver reflector. Go Black or Gold if you want to put an extra dimension to hotel or restaurant atmospheres. On request available in 24°.
/
CRI
90
CCT
2700K, 2700K|3000K|4000K, 3000K, 4000K
Chromaticity tolerance
3 MacAdam
Elclass
Class II
Housing material
Aluminum Die Cast
IP rating
IP20
Lifetime
50000h
Light source
927 (2700K / CRI90), 927 (2700K / CRI90)|930 (3000K / CRI90)|940 (4000K / CRI90)|Dim to Warm (1800K - 3000K / CRI90)|Tunable white (2700K - 6500K), 930 (3000K / CRI90), 940 (4000K / CRI90)
Light source energy class
E, E|F, F
Light source identifier
CLU028-1204C4-273H5M3-F1, CLU028-1204C4-273H5M3-F1|CLU028-1204C4-303H5M3-F1|CLU028-1204C4-403H5M3-F1, CLU028-1204C4-303H5M3-F1, CLU028-1204C4-403H5M3-F1
Luminaire color
Black, Black|White, White
Luminaire dimension
Ø105x80mm
Mains voltage
N/A
Net weight (kg)
00.34
Nominal fV (V)
34.1V, 350mA
Nominal fA (mA)
350mA
Optic
Reflector
Power supply
Separate Available
Reflector color
Black High Gloss, Black High Gloss|Black Matt|Chrome|Copper|Gold|Silver High Gloss|White, Black Matt, Chrome, Copper, Gold, Silver High Gloss, White
System efficiency
76lm/W, 76lm/W | 80lm/W | 81lm/W | 83lm/W | 84lm/W | 86lm/W | 87lm/W | 89lm/W | 90lm/W | 91lm/W | 92lm/W | 93lm/W, 80lm/W, 81lm/W, 83lm/W, 84lm/W, 86lm/W, 87lm/W, 89lm/W, 90lm/W, 91lm/W, 92lm/W, 93lm/W
System power
14W
Warranty
5Y
Light Color CCT
2700, 2700|3000|4000, 3000, 4000
Power (W)
12.5W
Lumen
1060 lm, 1060 lm|1120 lm|1130 lm|1140 lm|1160 lm|1180 lm|1200 lm|1220 lm|1240 lm|1260 lm|1270 lm|1290 lm|1300 lm, 1060lm, 1120 lm, 1120lm, 1130 lm, 1130lm, 1140 lm, 1140lm, 1160 lm, 1160lm, 1180 lm, 1180lm, 1200 lm, 1200lm, 1220 lm, 1220lm, 1240 lm, 1240lm, 1260 lm, 1260lm, 1270 lm, 1270lm, 1290 lm, 1290lm, 1300 lm, 1300lm
Beam angle
40°
Voltage (V)
34.1V
-
CRI90
-
CCT2700K, 2700K|3000K|4000K, 3000K, 4000K
-
Chromaticity tolerance3 MacAdam
-
ElclassClass II
-
Housing materialAluminum Die Cast
-
IP ratingIP20
-
Lifetime50000h
-
Light source927 (2700K / CRI90), 927 (2700K / CRI90)|930 (3000K / CRI90)|940 (4000K / CRI90)|Dim to Warm (1800K - 3000K / CRI90)|Tunable white (2700K - 6500K), 930 (3000K / CRI90), 940 (4000K / CRI90)
-
Light source energy classE, E|F, F
-
Light source identifierCLU028-1204C4-273H5M3-F1, CLU028-1204C4-273H5M3-F1|CLU028-1204C4-303H5M3-F1|CLU028-1204C4-403H5M3-F1, CLU028-1204C4-303H5M3-F1, CLU028-1204C4-403H5M3-F1
-
Luminaire colorBlack, Black|White, White
-
Luminaire dimensionØ105x80mm
-
Mains voltageN/A
-
Net weight (kg)00.34
-
Nominal fV (V)34.1V, 350mA
-
Nominal fA (mA)350mA
-
OpticReflector
-
Power supplySeparate Available
-
Reflector colorBlack High Gloss, Black High Gloss|Black Matt|Chrome|Copper|Gold|Silver High Gloss|White, Black Matt, Chrome, Copper, Gold, Silver High Gloss, White
-
System efficiency76lm/W, 76lm/W | 80lm/W | 81lm/W | 83lm/W | 84lm/W | 86lm/W | 87lm/W | 89lm/W | 90lm/W | 91lm/W | 92lm/W | 93lm/W, 80lm/W, 81lm/W, 83lm/W, 84lm/W, 86lm/W, 87lm/W, 89lm/W, 90lm/W, 91lm/W, 92lm/W, 93lm/W
-
System power14W
-
Warranty5Y
-
Light Color CCT2700, 2700|3000|4000, 3000, 4000
-
Power (W)12.5W
-
Lumen1060 lm, 1060 lm|1120 lm|1130 lm|1140 lm|1160 lm|1180 lm|1200 lm|1220 lm|1240 lm|1260 lm|1270 lm|1290 lm|1300 lm, 1060lm, 1120 lm, 1120lm, 1130 lm, 1130lm, 1140 lm, 1140lm, 1160 lm, 1160lm, 1180 lm, 1180lm, 1200 lm, 1200lm, 1220 lm, 1220lm, 1240 lm, 1240lm, 1260 lm, 1260lm, 1270 lm, 1270lm, 1290 lm, 1290lm, 1300 lm, 1300lm
-
Beam angle40°
-
Voltage (V)34.1V
