Delizia di Luce

Doppio Lente

The Doppio Lente is an adjustable led downlight with optical lenses. Double the looks, double the lighting power! This square downlight has top level looks, and so is his performance. Each light source can be controlled individually. LED€™s delight your hotel, restaurant, museum, office or home with Karizma Luce Doppio Lente.

iconwarranty5-60.svg icondali-57.svg icondimtowarm-54.svg iconreplaceablecontrol-56.svg iconreplaceableled-56.svg iconphasecutdim-48.svg
/

The Doppio Lente is an adjustable led downlight with optical lenses. Double the looks, double the lighting power! This square downlight has top level looks, and so is his performance. Each light source can be controlled individually. LED€™s delight your hotel, restaurant, museum, office or home with Karizma Luce Doppio Lente.

cct 2700K3000K4000K
chromaticity tolerance 3 MacAdam
cutout dimension 210x100mm
elclass Class II
housingmaterial Aluminum Die Cast
ip rating IP43/IP20
led power w 2x12.5W2x9W
lifetime 50000h
lightsource 927 (2700K / CRI90)930 (3000K / CRI90)940 (4000K / CRI90)
lightsource energyclass EF
lightsource identifier BXRE-27G0800-D-73BXRE-30G0800-D-73BXRE-40G0800-D-73CLU028-1202C4-403H5M3-F1CLU028-1204C4-273H5M3-F1CLU028-1204C4-303H5M3-F1
luminaire color BlackWhite
luminaire dimension 220x110x77mm
lightsource energy class EF
mains voltage N/A
netweight 01.34
nominal fa ma 350mA500mA
nominal fv v 18.4V33.8-35.9V
optic Lens
powersupply Separate Available
reflector color N/A
system efficiency 103lm/W61lm/W63lm/W74lm/W89lm/W91lm/W
system power 2x11.5W2x14W
product tags Phased out
warranty 5Y

Doppio Lente - Varianter

Bild SKU CCT Chromaticity tolerance Cutout dimension Elclass Housingmaterial IP rating LED Power (W) Lifetime Lightsource Lightsource energyclass Lightsource identifier Luminaire color Luminaire dimension Lightsource energy class Mains voltage Netweight Nominal fA [mA] Nominal fV [V] Optic Powersupply Reflector color System efficiency System power Product tags Warranty
120CB9272200 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CB9302200 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120CB9273600 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CB9303600 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120CB9276000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CB9306000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120FB9303000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120EB9274000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120FB9304000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120EB9276000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120FB9306000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120CW9272200 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CW9302200 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120CW9273600 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CW9303600 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120CW9276000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 927 (2700K / CRI90) F BXRE-27G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 61lm/W 2x11.5W Phased out 5Y
120CW9306000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 930 (3000K / CRI90) F BXRE-30G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 63lm/W 2x11.5W Phased out 5Y
120EW9273000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120FW9303000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120EW9274000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120FW9304000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120EW9276000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 White 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120FW9306000 3000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 930 (3000K / CRI90) E CLU028-1204C4-303H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 91lm/W 2x14W Phased out 5Y
120EB9273000 2700K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 927 (2700K / CRI90) F CLU028-1204C4-273H5M3-F1 Black 220x110x77mm F N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 89lm/W 2x14W Phased out 5Y
120DW9403600 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
120DW9406000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
120GB9403000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120GB9404000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120GB9406000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 Black 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120GW9403000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120GW9404000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120GW9406000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x12.5W 50000h 940 (4000K / CRI90) E CLU028-1202C4-403H5M3-F1 White 220x110x77mm E N/A 01.34 350mA 33.8-35.9V Lens Separate Available N/A 103lm/W 2x14W Phased out 5Y
120DB9402200 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
120DB9403600 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
120DB9406000 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 Black 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
120DW9402200 4000K 3 MacAdam 210x100mm Class II Aluminum Die Cast IP43/IP20 2x9W 50000h 940 (4000K / CRI90) F BXRE-40G0800-D-73 White 220x110x77mm F N/A 01.34 500mA 18.4V Lens Separate Available N/A 74lm/W 2x11.5W Phased out 5Y
